| 安装环境Installation environment | 室内或室外Indoor or outdoor | |
| 安装方式Installation | 无基坑安装, 高80MMNo foundation pit installation, high 80MM | |
| 有基坑安装，深80MMFoundation pit installation, deep 80MM | ||
| 安装空间installation space | 1300MM X 2000MM | Can be customized |
| 外形尺寸outline dimension | 1250MM X 1920MM(含自动翻板 automatic flap) | Can be customized |
| 平台尺寸Platform size | 900MM X 1426MM | Can be customized |
| 最大高度maximum altitude | 最大13米Maximum 13m | |
| 出入方向 Access directions | 180°贯通/ 90°/或原进原出 180°through /90°/ or original in / out | |
| 控制电源 Control Source | 220V/AC | |
| 电机功率 Motor Power | 1.1KW或1.5KW 220V/AC 1.1KWor1.5KW 220V/AC | |
| 电 源Power Supply | 220V/50HZ/25A | |
| 液压主机Hydraulic Host | 博勤公司原装产品，成套液压系统 Climb jade products complete hydraulic system | |
| 驱动方式Driving mode | 液压驱动hydraulic pressure | |
| 运行方式Running Mode: | 点动控制/或自动Jogging Control or automatic control | |
| 运行速度running speed | 80-120MM/秒100MM/sec | |
| 升降控制Lifting Control: | 采用“翘板自复位开关操作运行”Adopts “Operation by self-resetting switch of wane | |
| 过载保护Overload Protection | 过电流继电器控制Over-current relay control | |
| 护板形式 guard plate form | 90°或180°，互换配置 90°or 180°switch configuration | |
| 升降平台底板 the platform floor | 花纹钢板（静电喷塑）plate(electrostatic pensu) | |
| 整机颜色Machine color | 标准色：白色（可选）Standard Color: White (optional) | |
| 机箱面板Case Panel | 铝合金板（静 电 喷 塑）aluminium alloy plate(electrostatic pensu) | |
| 自动翻板Automatic flap | 75° | |
| 最大承重Maximum load bearing | 250KG/350KG | |
| 设备噪音noise | 60dB （液压系统内置 标准）Hydraulic system built-in Standards) | |
| 工作温度working temperature | -10C°/ +60C° | |
| 外控装置Extrocontrol Device | 外呼盒分别安置于设备上、下停层附近墙面，也可选用遥控器 The calling box shall be installed in the neighboring wall of the upper/lower layer of the equipment and remote controller shall also be used for options | |
| 安全装置 safety device | * 手动应急下降 Manual emergency descent * 平台主控面板优先 Platform master panel preferred * 紧急停止按钮 Emergency stop button * 层门与设备联动控制Layer and equipment linkage control * 防坠落机械装置 anti-fall mechanical device * 安全触板 security contact * 电控系统防过流过载保护 Electronic control system to prevent overcurrentoverload protection * 平台超重保护 Platform Overweight Protection * 液压油路防爆阀Hydraulic oil circuit explosion-proof valve | |
